Lexicon MPX G2 Service Manual

Lexicon
7-3
PART NO. DESCRIPTION QTY EFFECTI
■
INACTIVE REFERENCE
203-12497 RESSM,RO,1%,1/10W,8.25K OHM 2.00 R124,148
203-12499 RESSM,RO,1%,1/10W,45.3K OHM 1.00 R163
203-12523 RESSM,RO,1%,1/10W,6.98K OHM 1.00 R176
203-12896 RESSM,RO,1%,1/10W,147 OHM 1.00 R188
203-12897 RESSM,RO,1%,1/10W,976 OHM 2.00 R33,34
203-12898 RESSM,RO,1%,1/10W,47.5K OHM 2.00 R101,102
203-12934 RESSM,RO,1%,1/10W,82.5 OHM 2.00 R271,280
203-12935 RESSM,RO,1%,1/10W,1.65K OHM 3.00 R314-316
240-00608 CAP,ELEC,2.2uF,50V,RAD 1.00 C351
240-00614 CAP,ELEC,47uF,16V,RAD 29.00 C38,43,46,99,100,106
C107,112,113,118
C119,122,134-136
C139,195,196,205
C218,220,238,239
C241,260-262,265,416
240-05764 CAP,ELEC,330uF,25V,RAD,LO-PRO 3.00 C150,153,415
240-06611 CAP,ELEC,1000uF,25V,RAD 2.00 C395,403
240-07335 CAP,ELEC,47uF,25V,RAD,NON-POL 7.00 C16,17,22,23,31,32
C414
240-09367 CAPSM,ELEC,10uF,25V,NONPOL,20% 2.00 C40,45
240-09786 CAP,ELEC,100uF,25V,RAD,LOW ESR 1.00 C356
240-10758 CAPSM,ELEC,1uF,50V,20%,5.5mmH 3.00 C177,268,417
240-11827 CAPSM,ELEC,10uF,16V,20% 54.00 C10,11,62,64,66,67
C69,70,74-76,93-98
C142,145,146,148
C193,201,221,237
C270,273,275,278
C283,284,302,303
C305,307-309,311
C312,314,315,317
C318,321,322,327
C330,344,345,349
C350,363,413,420
240-12483 CAP,ELEC,100uF,10V,NONPOL,20% 3.00 C182,332,333
244-00662 CAP,MYL,.1uF,100V,RAD,5% 3.00 C255,291,293
244-01488 CAP,MYL,.22uF,100V,RAD,10% 5.00 C152,155,157,159,354
244-02342 CAP,MYL,.68uF,50V,RAD,10% 1.00 C219
244-06883 CAP,MYL,.01uF,100V,RAD,5% 2.00 C54,331
244-10423 CAP,MYL,.22UF,10%,RAD 1.00 C1
244-11588 CAP,MYL,.039uF,100V,RAD,10% 1.00 C215
244-12482 CAP,MYL,.15uF,50V,RAD,5% 2.00 C79,185
244-12490 CAP,MYL,.056uF,50V,10%,RAD 1.00 C210
245-09291 CAPSM,CER,470pF,50V,COG,5% 1.00 C352
245-09876 CAPSM,CER,.01uF,50V,Z5U,20% 1.00 C36
245-09895 CAPSM,CER,10pF,50V,COG,10% 13.00 C19,26,114,117,130
C133,167,168,227
C292,300,371,372
245-10561 CAPSM,CER,100pF,50V,COG,5% 6.00 C55-59,61
245-10562 CAPSM,CER,150pF,50V,COG,10% 15.00 C2,7,8,13,14,35,39
C44,49,50,151,154
C156,158,355
245-10587 CAPSM,CER,18pF,50V,COG,10% 8.00 C103,269,274,326
C382,383,387,388
245-10976 CAPSM,CER,47pF,50V,COG,5% 1.00 C172
245-10977 CAPSM,CER,330pF,50V,COG,5% 7.00 C200,285,287,294
C296,338,340
245-11594 CAPSM,CER,2200pF,50V,COG,5% 3.00 C279,280,346
245-11595 CAPSM,CER,.01uF,50V,COG,5% 8.00 C225,226,231,234
C249,250,404,406
245-11598 CAPSM,CER,8200pF,50V,COG,5% 1.00 C165
245-11625 CAPSM,CER,33pF,50V,COG,5% 1.00 C88
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 219.00 C3-6,9,12,15,18,20
C24,27-30,33,34,41
C42,47,48,51-53,60
C63,65,68,71-73,77
C78,80-82,84-87
C90-92,101,102,104
C105,108-111,115
