Lexicon MPX G2 Service Manual

MPX G2 Service Manual
7-2
PART NO. DESCRIPTION QTY EFFECTI
■
INACTIVE REFERENCE
R279,281,283,285
R286,300-304,317
R320,322-325,328
R341,342,352
R421,429,432,446
R447,450,455
203-10896 RESSM,RO,1%,1/10W,1.00K OHM 48.00
■
10/06/98 R3,43-46,55,60
R64,65,71,80,105
R110,135,141,164
R170,171,177,178
R229,258-261,306
R307,340,345-347
R350,393,395,397,399
R401,403,405,407
R412-414,437,439
R441,443,445
203-10896 RESSM,RO,1%,1/10W,1.00K OHM 49.00 10/06/98
■
R3,43-46,55,60,64
R65,71,80,105,110
R135,141,164,170,171
R177,178,229,232
R258-261,306,307,340
R345-347,350,393,395
R397,399,401,403,405
R407,412-414,437,439
R441,443,445
203-10897 RESSM,RO,1%,1/10W,2.00K OHM 36.00 R107-109,112,113
R122,123,125-131
R147,149-158,169
R174,175,190,191
R209-212,236,237
203-10898 RESSM,RO,1%,1/10W,4.87K OHM 6.00 R246,247,251,253
R310,312
203-10992 RESSM,RO,1%,1/10W,6.04K OHM 3.00 R111,134,143
203-11080 RESSM,RO,1%,1/10W,1.15K OHM 5.00 R15,18,222,291,294
203-11083 RESSM,RO,1%,1/10W,49.9K OHM 2.00 R54,59
203-11110 RESSM,RO,1%,1/10W,16.5K OHM 1.00 R167
203-11493 RESSM,RO,1%,1/10W,3.92K OHM 1.00 R448
203-11519 RESSM,THIN,1%,1.00M OHM,MELF 1.00 R2
203-11546 RESSM,RO,1%,1/10W,14.0K OHM 1.00 R198
203-11547 RESSM,RO,1%,1/10W,715K OHM 1.00 R199
203-11707 RESSM,RO,1%,1/10W,150K OHM 1.00 R172
203-11723 RESSM,RO,1%,1/10W,4.75K OHM 2.00 R32,35
203-11724 RESSM,RO,1%,1/10W,150 OHM 11.00 R159-161,197,265-268
R308,334,335
203-11731 RESSM,RO,1%,1/10W,1.62K OHM 1.00 R221
203-11737 RESSM,RO,1%,1/10W,5.76K OHM 4.00 R201,205,214,217
203-11739 RESSM,RO,1%,1/10W,8.66K OHM 2.00 R239,242
203-11742 RESSM,RO,1%,1/10W,75.0K OHM 1.00 R173
203-11743 RESSM,RO,1%,1/10W,100K OHM 12.00 R48,121,165,166,168
R186,187,208,234
R305,321,452
203-11744 RESSM,RO,1%,1/10W,1.00M OHM 12.00 R5,7,10,12,21,23
R26,28,50,139
R145,369
203-11889 RESSM,RO,1%,1/10W,110 OHM 8.00 R89-92,296-299
203-11891 RESSM,RO,1%,1/10W,2.26K OHM 1.00 R226
203-11897 RESSM,RO,1%,1/10W,21.5K OHM 1.00 R227
203-11996 RESSM,RO,1%,1/10W,6.49K OHM 2.00 R277,288
203-11997 RESSM,RO,1%,1/10W,13.7K OHM 4.00 R203,206,216,218
203-11998 RESSM,RO,1%,1/10W,20.0K OHM 9.00 R100,183,193,228
R329-332,422
203-12249 RESSM,RO,1%,1/10W,5.36K OHM 4.00 R200,204,213,219
203-12383 RESSM,RO,1%,1/10W,5.11K OHM 4.00 R235,240,276,287
203-12476 RESSM,RO,1%,1/10W,4.02K OHM 2.00 R133,142
203-12493 RESSM,RO,1%,1/10W,806 OHM 2.00 R192,194
203-12495 RESSM,RO,1%,1/10W,3.16K OHM 4.00 R202,207,215,220
203-12496 RESSM,RO,1%,1/10W,3.24K OHM 2.00 R238,241
