Lexmark 4513-630 - Fan Removal

4-16
4513-630, -63W, -6EW
Fan removal
1. Remove the right side cover. See “Right side cover assembly removal” on page 3-62.
2. Disconnect the cable (A) from the controller board, and remove the two screws (B) holding the fan to the
right side frame.
3. Remove the fan.
A BB
