7-20 Service Manual
5026
Assembly 12: Options and features
Index P/N
Units/
opt
Units/
FRU
Description
NS 40X5317 1 1 Parts packet, ISP thumbscrew and standoff
NS 40X5315 1 1 Wireless ISP thumbscrew
NS 40X5318 1 1 ISP thumbscrew
NS 40X5136 1 1 Parts packet, screw (contains each screw used in the printer, with the
exception of the parts specifically called out.) See “Screw and retainer
identification table” on page 4-3.
NS 40X5301 1 1 256 MB SDRAM
NS 40X5302 1 1 512 MB SDRAM
NS 40X5303 1 1 1024 MB SDRAM
NS 40X5704 1 1 256 MB flash card
NS 40X5969 1 1 Korean font card
NS 40X5971 1 1 Traditional Chinese font card
NS 40X5970 1 1 Simplified Chinese font card
NS 40X5972 1 1 Japanese font card
NS 40X7051 1 1 Lexmark PrintCryption™ card
NS 40X4826 1 1 MarkNet™ N8120 10/1000
NS 40X4827 1 1 MarkNet N8130 10/100 fiber
NS 40X4823 1 1 Parallel 1284-B interface card adapter
NS 40X4819 1 1 Serial interface card adapter
NS 40X7058 1 1 160 GB hard drive assembly
NS 7377200 1 1 Option drawer relocation kit
NS 40X5281 1 1 High-capacity input tray (HCIT) relocation kit
NS 40X5316 1 1 14-pin JST cable assembly for ISP interface cable
NS 40X8332 1 1 C74x relocation kit
NS 40X1367 1 1 10 ft. parallel cable, ROHS
NS 40X1368 1 1 2 meter USB cable, ROHS
NS 40X1592 1 1 Print server 4-port USB
NS 40X1593 1 1 Print server 1-port USB
NS 40X1594 1 1 Print server parallel
NS 40X8321 1 1 C746x forms + barcode
NS 40X8322 1 1 C748x forms + barcode
NS 40X7062 1 1 Wireless US 802.11b/g/n ISP adapter
NS 40X7063 1 1 Wireless EU 802.11b/g/n ISP adapter
NS 40X8324 1 1 C746x IPDS SCS TNe card
NS 40X8325 1 1 C748x IPDS SCS TNe card
NS 40X8327 1 1 C746x Prescribe card
NS 40X8328 1 1 C748x Prescribe card
NS 40X8359 1 1 Caster front wheel
NS 40X8478 1 1 Caster base
