Installing a 500-sheet drawer
7
Installing and removing options
Installing a 500-sheet drawer
Your printer supports up to three additional 500-sheet drawers. However, if you install a 2000-sheet drawer, you can only
add one additional 500-sheet drawer.
Warning: If you have an optional duplex unit and a 2000-sheet drawer, you must install a 500-sheet drawer
between the duplex unit and the 2000-sheet drawer.
1 Unpack the 500-sheet drawer and remove any packing material.
2 Place the drawer in the location you have chosen for your printer, or install it on another drawer. To install it on
another drawer:
a Align the holes in the 500-sheet drawer with the positioning posts on the lower drawer.
b Lower the 500-sheet drawer into place. Make sure it is seated securely on the other drawer.
3 If you are installing a 500-sheet drawer on top of a 2000-sheet drawer, secure the drawers with stabilizing screws.
a Insert the screws through the holes next to the positioning posts on the 500-sheet drawer.
b Hand-tighten the screws.
Even when fully inserted, the screws allow some space between the drawers.
4 Install another 500-sheet drawer, or continue with Installing a duplex unit.
