Lexmark CS410 Technical Reference Manual

Two-dimensional bar codes
91
Two-dimensional bar codes
HIBC 39/128
Key Type Range Default value Description
/Symbology name n/a n/a Required
/HIBC128PAS
/HIBC128SLS
/HIBC39PAS
/HIBC39SLS
/Units name /300ths
/600ths
/1200ths
/600ths Optional
/Units is used in the calculations that
follow.
/Height int 150–600 (dec) 240 (dec)
F0 (hex)
Optional
Sets the bar height in /Units
Note: Values beyond the defined range
are appropriately clipped and set to the
minimum and maximum values.
/Bars [int] Minimum:
[5] (dec)
[05] (hex)
Maximum:
[ 27] (dec)
[1B] (hex)
[6] (dec)
[06] (hex)
Optional
Sets the bar widths in /Units
Note: Values beyond the defined range
are appropriately clipped and set to the
minimum and maximum values.
/Spaces [int] Minimum:
[5] (dec)
[05] (hex)
Maximum:
[ 27] (dec)
[1B] (hex)
[6] (dec)
[06] (hex)
Optional
Sets the space widths in /Units
Note: Values beyond the defined range
are appropriately clipped and set to the
minimum and maximum values.
/EmbedText name /NoText
/Under
/Above
/Embedded
/HalfEmbedded
/Under Optional
Defines if and where the HRT is printed

Lexmark CS410 Specifications

General

Print Technology	Color Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	256 MB
Processor Speed	800 MHz
Standard Input Capacity	250 sheets
Connectivity	USB, Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Monthly Duty Cycle	75, 000 pages
Maximum Memory	2304 MB
Duplex Printing	Yes
Mobile Printing	Yes
