5 Insert the new ﬁnisher bin.

6 Close the ﬁnisher door.

7 Turn on the printer.

Replacing the paper bail

1 Pinch the left side of the paper bail to unlock it.

2 Remove the used paper bail.

3 Unpack the new paper bail.

Maintain the printer 368
