Parts catalog 7-3
4512-420, -430
Assembly 1: Covers
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
1—1 40X2835 1 1 Top cover assembly (includes narrow media sensor)
2 40X2812 1 1 Top cover right and left flags
3 40X2839 1 1 Rear upper and lower cover assembly
4 40X2858 1 1 Legal extender dust cover
5 40X2837 1 1 Right side cover
6 40X2843 1 1 Optional media drawer assembly
7 40X2844 1 1 Tray 2 assembly
8 40X2855 1 4 Tray 2 wear strips
9 40X2854 1 4 Tray 1 wear strips
10 40X2842 1 1 Main tray
11 40X2836 1 1 Left side cover
12 40X2815 1 1 LCD bezel cover, E350d
12 40X2816 1 1 LCD bezel cover, E352dn
13 40X2840 1 1 Front access cover assembly
