Parts catalog 7-5
4512-420, -430
Assembly 2: Electronics
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
2–1 40X2803 1 LSU, E350d/E352dn
2 40X2800 1 Fuser assembly, 110 V
2 40X2801 1 Fuser assembly, 220 V
2 40X2802 1 Fuser assembly, 100 V
3 40X2833 1
1
1
1
1
Miscellaneous cable assemblies
Thermistor
LVPS/HVPS to controller card
Main drive gear assembly (motor to controller card)
Fuser power (LVPS to fuser)
4 40X2823 1 1 Duplex and media sensor assembly
5 40X2813 1 1 Cover open sensor assembly
6 40X2856 1 1 Narrow media sensor
7 40X2828 1 1 Cooling fan
8 56P2076 1 1 Toner low sensor (RO)
9 40X2805 1 1 Controller card, E352dn
9 40X2851 1 1 Controller card, E350d
10 40X2819 1 LVPS/HVPS card assembly, 110 V
10 40X2820 1 LVPS/HVPS card assembly, 220 V
11 40X2809 1 LCD operator panel assembly, E350d/E352dn
12 40X2824 1 1 Manual input sensor assembly
13 40X2845 1 1 Pickup and manual feed solenoids
14 40X2826 1 1 Main drive gear assembly
15 40X2846 1 1 Reversing solenoid
