Lexmark E350d

Parts catalog 7-7
4512-420, -430
Assembly 3: Frame
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
3–1 40X2834 1 Media exit guide assembly
2 40X2822 1 Transfer roll, bearings, gear, spring (CBM)
3 40X2858 1 1 Legal extender dust cover
4 40X2850 N/A
4
4
4
2
2
Screws, miscellaneous (actual size)
TP2NCX3X6PF-Ni
TP2C-4.0+8PF-Ni
M3.0*0.5+6PF-Ni
M3.0*0.5+4PF-Ni
M3.5*0.6+6P-Ni
5 40X2853 1 1 ACM drive shaft assembly
6 40X2841 1 1 Complete duplex assembly
7 56P1820 2 Paper feed, ACM tires (RO)
8 40X2838 1 1 Media (ACM) drive assembly
9 40X2857 1 1 Upper front frame assembly
10 40X2830 1 1 Manual feed clutch CBM
11 40X2831 1 1 Media feed ACM clutch CBM
12 40X2832 1 1 Media level indicator CBM
13 40X2825 1 1 Developer drive/access door link
14 40X2829 1 1 Developer drive coupling assembly
15 40X2821 1 1 Duplex drive gear CBM
NS 40X2847 1 1 110 V maintenance kit
NS 40X2848 1 1 220 V maintenance kit
NS 40X2849 1 1 100 V maintenance kit
Note: Kit contains the following:
Fuser (40X2800, 40X2801, or 40X2802)
Exit guide (40X2834)
Tray 1 ACM feed tires (56P1820)
Transfer roll CBM (40X2822)
