4 Housing
5 Interface cable
4 Install the ISP into its housing.
5 Secure the ISP in place and attach the ISP extended cable.
6 Open, and then remove the controller board access cover.
Warning—Potential Damage: Controller board electronic components are easily damaged by static
electricity. Touch a metal surface on the printer before touching any controller board electronic
components or connectors.
Upgrading and migrating 161
