3 Squeeze and then slide the length guide tab to the correct position for the size of the paper you are loading.
A
6
A
5
LGL
A5
B5
EXEC
2
1
Notes:
• For some paper sizes like letter, legal, and A4, squeeze and slide the length guide tab backward to
accommodate their length.
• When loading legal‑size paper, the length guide extends beyond the base, leaving the paper exposed to
dust. To protect the paper from dust, you can purchase a dust cover separately. For more information,
contact customer support.
• If you are loading A6‑size paper in the standard tray, then squeeze and slide the length guide tab toward the
center of the tray to the A6‑size position.
• Make sure the width and length guides are aligned with the paper size indicators on the bottom of the tray.
13
