Lexmark MS725 Service Manual

Action Yes No
Step 15
a Remove the left cover from the optional tray whose motor will
be tested. See
“250‑ and 550-sheet tray left cover removal”
on page 496.
b Enter the Diagnostics menu, and then navigate to:
Additional input tray diagnostics > Motor tests
c Select the motor (Pass-through (tray 2)), and then touch Start.
Does the motor run?
Go to step 18. Go to step 16.
Step 16
Reseat the cable on the motor and on the optional tray controller
board.
Does the problem remain?
Go to step 17. The problem is
solved.
Step 17
Replace the motor (tray 2 transport). See
“Motor (250‑ and 550-
sheet tray transport) removal” on page 504.
Does the problem remain?
Go to step 18. The problem is
solved.
Step 18
a Remove the left cover from the optional tray whose motor will
be tested. See
“250‑ and 550-sheet tray left cover removal”
on page 496.
b Enter the Diagnostics menu, and then navigate to:
Additional input tray diagnostics > Motor tests
c Select the motor (Pick (tray x)), and then touch Start.
Note: For tray x, choose the tray number of the aected
source tray.
Does the motor run?
Go to step 21. Go to step 19.
Step 19
Reseat the cable on the motor and on the optional tray controller
board.
Does the problem remain?
Go to step 20. The problem is
solved.
Step 20
Replace the source tray paper feeder. See
“250‑ and 550-sheet
tray paper feeder removal” on page 504.
Does the problem remain?
Go to step 21. The problem is
solved.
4064
Diagnostics and troubleshooting
149

Lexmark MS725 Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	- ppm
Display	LCD
Product color	Black, White
Display diagonal	2.4 \
Market positioning	-
Paper tray media types	Card stock, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Folio (media size), Oficio (media size), Universal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Security features	IPSec, SNMPv3, 802.1x Authentication: MD5, MSCHAPv2, LEAP, PEAP, TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
USB connector	USB Type-A / USB Type-B
USB 2.0 ports quantity	2
Maximum internal memory	4608 MB
Sound pressure level (printing)	56 dB
Sound pressure level (duplex printing)	55 dB
Power consumption (off)	0.2 W
Power consumption (sleep)	1.3 W
Power consumption (printing)	720 W
Energy Star Typical Electricity Consumption (TEC)	1.28 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	IBM AIX 6.1, IBM AIX 7.1, Novell Open Enterprise Server, Solaris 10 SPARC, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Printing colors	Black
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 75000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XML, XPS
Total input capacity	650 sheets
Total output capacity	550 sheets
Maximum input capacity	4400 sheets
Maximum number of input trays	6
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	650.2 mm
Package width	551.2 mm
Package height	563.9 mm
Package weight	30980 g

Weight and Dimensions

Depth	510.5 mm
Width	428 mm
Height	444.5 mm
