2 Open the controller board shield using the green handle.
1
2
3 Use the following illustration to locate the option card connector.
Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity.
Touch something metal on the printer before touching any controller board electronic components or
connectors.
4 Close the shield, and then the access door.
1
2
