Understanding the parts of the printer
3
1
2
4
5
6
7
8
9
10
11
12
Use the To
1 Scanner lid Access the scanner glass.
2 Scanner glass Scan and copy photos and documents.
3 Automatic Document Feeder (ADF) Scan, copy, or fax multiple-page letter-, legal-, and A4-size documents.
4 ADF tray Load original documents in the ADF. Recommended for scanning, copying, or
faxing multiple-page documents.
Note: Do not load postcards, photos, small items, or thin media (such as
magazine clippings) into the ADF. Place these items on the scanner glass.
5 ADF paper guide Keep paper straight when feeding into the ADF.
6 ADF output tray Hold documents as they exit from the ADF.
7 Wi-Fi indicator Check wireless status.
8 Memory card slot Insert a memory card.
9 PictBridge and USB port Connect a PictBridge-enabled digital camera, a USB Bluetooth adapter, or a
flash drive to the printer.
10 Printer control panel Operate the printer.
11 Paper tray Load paper.
12 Paper exit tray Hold paper as it exits.
About your printer
