Lexmark X860de - Page 14

Parts catalog 7-13
7500-432, -632, and -832
Assembly 7: Finisher—punch
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
1 40X0854 1 1 Punch carriage shift motor assembly
2 40X0855 1 1 Punch carriage assembly
3 40X0856 1 1 Sensor (punch unit side reg) assembly
• Sensor (punch unit side reg1)
• Sensor (punch unit side reg2)
•Bracket
4 40X0857 1 1 2/3 punch hammer sub-assembly
4 40X0858 1 1 2/4 punch hammer sub-assembly
5 40X0859 3 1 Punch media stopper assembly
6 40X3937 1 1 2/4 punch unit assembly
6 40X6865 1 1 2/3 punch unit assembly
7 40X0862 1 1 Punch waste box (non-booklet making finisher)
7 40X3946 1 1 Punch waste box (booklet making finisher)
8 40X0930 1 1 Punch waste box full cable assembly
9 40X0864 1 1 Sensor (punch waste box full) (non-booklet making finisher only)
10 40X0865 1 1 Punch waste box set cable assembly
11 40X0861 1 1 Sensor (punch waste box set)
12 40X3944 1 1 Sensor (punch unit motor encoder)
13 40X3943 1 1 Punch unit motor assembly
14 40X0850 1 1 Sensor (punch hole select)
15 40X0850 1 1 Sensor (punch cam front)
16 40X0850 1 1 Sensor (punch unit HP)
17 40X0853 1 1 Punch unit cable assembly
18 40X3938 1 1 Sensor (punch carriage shift HP)
Note: Assembly index items 11, 13, 14, 15, and 17 are identical sensors with different functions; therefore, they are the
same part number with different descriptions.
