Parts catalog 7-19
7500-432, -632, and -832
Assembly 10: Finisher—eject and compiler unit
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
1 40X0883 1 1 Media compiler unit assembly (this comes assembled)
2 40X0850 1 1 Sensor (rear tamper HP)
3 40X0850 1 1 Sensor (front tamper HP)
4 40X0825 1 1 Sensor (compiler media in)
5 40X4150 1 1 Media eject shaft assembly (booklet finisher only)
5 40X0886 1 1 Media eject shaft assembly
6 40X0887 3 1 Clamp paddle
7 40X0888 15 1 Bushing 6 mm
8 40X1388 4 1 Bushing 8 mm
9 40X0889 2 1 Media eject shaft gear 39T
10 40X0890 1 2 Media eject clutch kit includes:
• Media eject clutch
• Media eject clutch actuator
11 40X0825 1 1 Sensor (media eject shaft HP)
12 40X0891 1 1 Media eject motor assembly
Note: Assembly index items 2 and 3 are identical sensors with different functions; therefore, they are the same part
number with different descriptions.
