Parts catalog 7-25
7500-432, -632, and -832
Assembly 13: Finisher—transport and upper drive
Asm-
Index
Part
number
Units/
option
Units/
FRU
Description
1 40X0918 4 1 Upper media exit pinch roll assembly
2 40X0893 1 1 Sensor (upper media exit)
3 40X0919 1 1 Upper media exit roll assembly
4 40X0908 1 1 Sensor (finisher media entrance)
5 40X0824 8 1 Magnetic catch
6 40X0888 15 1 Bushing 6 mm
7 40X0920 1 1 Upper pinch guide assembly (this comes assembled)
8 40X0921 1 1 Sensor (diverter gate)
9 40X0922 1 1 Diverter gate sensor upper cable assembly
10 40X0923 2 1 Upper media transport roll assembly
11 40X0924 1 1 Buffer roll drive pulley/gear 53/23T
12 40X0912 3 3 Belt tensioner bracket kit includes:
• Belt idler pulley
• Spring
• Belt tensioner bracket
13 40X0925 2 1 Upper media transport roll drive pulley 20T
14 40X0897 3 1 Belt idler pulley
15 40X0913 4 1 Ball bearing 6 mm
16 40X0928 1 1 Belt (buffer transport) 19.8 cm
17 40X0929 1 1 Belt (exit) 27.7 cm
18 40X0926 1 1 Upper media exit roll drive pulley/gear, 20T/20T
19 40X0927 1 1 Upper media exit roll drive gear 20T
20 40X0910 1 1 Drive motor (buffer/transport)
21 40X0910 1 1 Drive motor (exit)
