2-1. Instrument cluster
Vehicle status information and indicators
Hybrid System Indicator
Displays hybrid system output or regeneration level (P.103)
This display changes to a tachometer depending on the driving mode, and can be set to
show the tachometer in any driving mode on the settings display. (P.111, 267)
•Rev indicator (P.104)
•Rev peak (P.104)
Speedometer
Shift position and shift range (P.191)
Odometer and trip meter display (P.105)
Fuel gauge
Displays the quantity of fuel remaining in the tank
In the following situations, the actual quantity of fuel remaining in the tank may not be dis-
played correctly. Refer to P.104 if the actual quantity of fuel remaining in the tank is not dis-
played correctly.
• A small amount of fuel is added.
• Fuel is added with the fuel gauge near or at “1/1”.
• The vehicle is stopped on an uneven surface, such as a slope.
• The vehicle is driven on a slope or around a curve.
Engine coolant temperature gauge
Displays the engine coolant temperature
Multi-information display
Presents the driver with a variety of vehicle data (P.107)
Displays warning messages if a malfunction occurs (P.415)
Q Hybrid System Indicator
Charge area
Shows regeneration
*
status.
Regenerated energy will be used to
charge the hybrid battery (traction bat-
tery).
Hybrid Eco area
Shows that gasoline engine power is not
being used very often.
The gasoline engine will automatically stop
and restart under various conditions.
Eco area
Shows that the vehicle is being driven in an
Eco-friendly manner.
By keeping the bar display within Eco area,
more Eco-friendly driving can be
achieved.
Power area
C
D
E
F
G
H
I
A
B
C
D
