119
2
2-1. Instrument cluster
Vehicle status information and indicators
Side display (12.3-inch display
model)
The image shows all the arrows as an
example. The actual display will vary
depending on conditions.
Gasoline engine
Hybrid battery (traction battery)
Tires
Q Hybrid battery (traction battery) status
The display changes in 8 levels according
to the remaining charge amount of the
hybrid battery (traction battery).
O The figure shows the multi-information
display as an example for explanation.
O These images are examples only, and
may vary slightly from actual conditions.
Low
High
Press the “MENU” button on the
Remote Touch, then select on the
menu screen, and then select “Trip
information” or “History”.
Q Trip information
If a screen other than “Trip informa-
tion” is displayed, select “Trip informa-
tion”.
Resetting the consumption data
Fuel consumption in the past 15
minutes
Current fuel consumption
Regenerated energy in the past 15
minutes
One symbol indicates 50 Wh. Up to 5
symbols are shown.
Average vehicle speed since the
hybrid system was started.
Elapsed time since the hybrid sys-
tem was started.
Cruising range
Average fuel consumption for the past 15
minutes is divided by color into past aver-
ages and averages attained since the
power switch was last turned to ON mode.
Use the displayed average fuel consump-
tion as a reference.
The image is an example only, and may
Consumption
A
B
C
A
B
A
B
C
D
E
G
