ES350_300h_OM_OM33A60U_(U)
843
8-1. Specifications
8
Vehicle specifications
*
1
: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N,
51.0 kgf) while the engine <hybrid system> is running <operating>.
*
2
: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N,
30.6 kgf).
Brakes
Pedal clearance*
1
Gasoline vehicles
3.58 in. (91 mm) Min.
Hybrid vehicles
3.62 in. (92 mm) Min.
Pedal free play 0.04 — 0.24 in. (1.0 — 6.0 mm)
Front and rear brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake pedal travel *
2
7 10 clicks
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
Steering
Free play Less than 1.2 in. (30 mm)
