Lexus LS 430 - Microphone Installation

LS 430 CMT - Dual band portable phone
40
2.1 Remove the map light lens .
2
2.2 Remove the overhead module .
: Connector (1x)
: Screw (2x)
101
31
3
2.3 Remove the screw .
Connect the microphone on the
microphone amplifier after installing
one screw on the overhead module
.
: Screw (1x)
107
3
107
9
15
107
2. MICROPHONE INSTALLATION
2
3
101
31
107
9
15
3
