LS 430
CMT - Dual band portable phone
50
4.1 Remove the luggage compartment car-
pet and floor board .
16
4.2 Remove the luggage compartment floor
boards (RH) .
: Clip (1x)
112
17
4.3 Remove the luggage compartment floor
boards (LH) .
: Clip (1x)
112
18
4. PSE INSTALLATION
16
17
112
112
