Lexus LS 430 - Page 21

LS 430 CMT - Dual band portable phone
51
Disconnect
Pull
Pull
Push Push
4.5 Remove the luggage cable cover .
21
4.6
a) Remove the luggage compartment light
.
: Hook (1x)
: Clip (1x)
b) Remove the filter cover (if applica-
ble).
: Clip (2x)
108
23
104
103
22
4.4
a) Remove the D-ring tie downs (LH +
RH).
b) Remove the luggage compartment rear
trim .
: Clip (4x)
: Bolt (2x)
: Clip (4x)
112
105
102
19
20
112
(4x)
19
(4x)
102
105
20
21
flat blade screwdriver
21
21
22
104
103
23
108
