LG 24MP56HQ User Manual

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Using the Kensington security system
The Kensington security system connector is
located at the back of the Monitor set. For more
information of installation and using, refer to the
manual supplied with the Kensington security
system or visit http://www.kensington.com .
Connect the Kensington security system cable
between the Monitor set and a table.
The Kensington security system is optional.
You can obtain it from most electronics stores.
NOTE
When you adjust the angle, do not hold the
bottom of the Monitor set frame as shown on
the following illustration, as may injure your
fingers.
Do not touch or press the screen when
adjusting the angle of the monitor.
Do not hold this set like below picture.Monitor
screen can detach from stand base and injure
your body.
WARNING
Tilt from +20 to -5 degrees up or down to adjust
the angle of the Monitor set to suit your view.
NOTE
Front
Rear

LG 24MP56HQ Specifications

General

Panel type	AH-IPS
Aspect ratio	16:9
Backlight type	W-LED
Display surface	Matt
Display diagonal	23.8 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
USB Type-A downstream ports quantity	0
Product color	Black, Grey
LED indicators	Power
Tilt angle range	20 - -5 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Annual energy consumption	35 kWh
Power consumption (standby)	0.3 W
Power consumption (typical)	24 W
Cables included	VGA

Weight and Dimensions

Depth (with stand)	188 mm
Height (with stand)	436 mm
Weight (with stand)	3100 g
Depth (without stand)	- mm
Width (without stand)	554 mm
Weight (without stand)	- g
