LG 24MP56HQ User Manual

15
ENG
ENGLISH
CUSTOMIZING SETTINGS
1
Press
MENU
button on the rear of the Monitor set to
display the
Menu
OSD.
2
Select the "
Next Menu
" button to enter the more
option settings.
3
Enter to
by pressing the ▼ button.
4
Set the options by pressing the ◄ or ► or ▼
buttons.
5
Select
EXIT
to leave the OSD menu.
To return to the upper menu or set other menu items,
use the up arrow ( ) button.
Each option is explained below.
Menu > Next Menu > Picture Description
Sharpness
To adjust the clearness of the screen.
Black Level
You can set the offset level. If you select 'High', the screen will be bright and if
you select ‘Low’, the screen will be dark.(only for HDMI input)
* Offset?As the criteria for video signal, it is the darkest screen the monitor can
show.
Over Scan
To select the range of output image for DTV timing in HDMI input.(only for HDMI
input)Recommend overscan function to turn on when connect AV equipment.

LG 24MP56HQ Specifications

General

Panel type	AH-IPS
Aspect ratio	16:9
Backlight type	W-LED
Display surface	Matt
Display diagonal	23.8 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
USB Type-A downstream ports quantity	0
Product color	Black, Grey
LED indicators	Power
Tilt angle range	20 - -5 °
Panel mounting interface	75 x 75 mm
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Annual energy consumption	35 kWh
Power consumption (standby)	0.3 W
Power consumption (typical)	24 W
Cables included	VGA

Weight and Dimensions

Depth (with stand)	188 mm
Height (with stand)	436 mm
Weight (with stand)	3100 g
Depth (without stand)	- mm
Width (without stand)	554 mm
Weight (without stand)	- g
