12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Using the Kensington lock
The Kensington security system connector is locat-
ed at the back of the Monitor set.
For more information on installation and usage,
refer to the Kensington lock user manual or visit
the website at http://www.kensington.com.
Connect the Kensington security system cable
between the Monitor set and a table.
y
The Kensington security system is optional.
You can obtain additional accessories from
most electronics stores.
NOTE
y
An image displayed on the monitor's screen
does not rotate according to the screen ori-
entation.
NOTE
y
Take care when rotating the monitor if the
cable is connected.
WARNING
1
Raise the monitor up to the maximum height.
2
Adjust the angle of the monitor in the
direction of the arrow as shown in the figure.
3
Rotate the monitor clockwise as shown in the
figure.
4
Complete the installation by rotating the monitor
90° as shown below.
To Next Page
