LG 29UM67-P User Manual

21
ENG
ENGLISH
USING THE MONITOR
y
There may be no video or audio output de-
pending on the DP version of the PC.
y
The DisplayPort cable may not be available
in some areas.
DisplayPort connection
Transmits the digital video and audio signals from
your PC to the monitor. Connect your PC to the
monitor using the display port cable as illustrated
below.
Press the menu button and then select the input
option from the input menu.
NOTE
(sold separately)
HDMI connection
Transmits the digital video and audio signals from
your PC and A/V devices to the monitor. Connect
your PC and AV device to the monitor with the
HDMI cable as illustrated below.
Press the menu button and then select the input
option from the input menu.
NOTE
y
If you use HDMI PC, it can cause compatibility
problem.
y
Use a certified cable with the HDMI logo
attached. If you do not use a certified HDMI
cable, the screen may not display or a
connection error may occur.
y
Recommended HDMI cable types
- High-Speed HDMI
®
/
TM
Cable
- High-Speed HDMI
®
/
TM
Cable with Ethernet

LG 29UM67-P Specifications

General

3D	No
HD type	2K Ultra HD
Panel type	AH-IPS
Pixel pitch	0.264 x 0.264 mm
Aspect ratio	21:9
Backlight type	W-LED
Display surface	-
Display diagonal	29 \
Display resolution	2560 x 1080 pixels
Display technology	LED
Horizontal scan range	30 - 90 kHz
Supported video modes	1080p
Viewable size, vertical	290.2 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	677 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1080
On/off switch	Yes
DVI-D ports quantity	1
VGA (D-Sub) ports quantity	0
RMS rated power	14 W
Number of speakers	2
Certification	TCO 6.0, TÜV, CE, EMC, EN, UL, cUL, FCC-B
Product color	Black
Tilt angle range	5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	DEU, ENG, ESP, FIN, FRE, GRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	90 - 240 V
AC input frequency	47/63 Hz
Power consumption (max)	47 W
Annual energy consumption	53 kWh
Power consumption (standby)	0.3 W
Power consumption (typical)	36 W
Sustainability certificates	ENERGY STAR
Package depth	151 mm
Package width	405 mm
Package height	814 mm
Package weight	8940 g
Cables included	Audio (3.5mm), HDMI

Weight and Dimensions

Depth (with stand)	181 mm
Height (with stand)	418 mm
Weight (with stand)	6200 g
Depth (without stand)	64 mm
Width (without stand)	703 mm
Height (without stand)	328 mm
Weight (without stand)	5200 g
