LG 31MU97C User Manual

ENGLISH
11
ASSEMBLING AND PREPARING
Pivot Feature
The pivot feature allows the monitor to rotate 90°
clockwise.
Stand
Head
WARNING
y
To avoid scratching the stand base, make sure
that when rotating the monitor using the pivot
feature, the stand does not make contact with
the monitor.
1
Raise the monitor to the maximum height.
2
Adjust the angle of the monitor in the direction
of the arrow as shown in the figure.
15°
3
Rotate the monitor clockwise as shown in the
figure.
4
Complete the installation by rotating the moni-
tor 90° as shown below.
y
Auto Pivot feature of the display is not sup-
ported.
y
The screen can be rotated easily using the
screen pivot shortcut key provided with your
Windows operating system. Note that some
Windows versions and some graphics card
drivers may use different settings for the
screen pivot key or may not support the pivot
key at all.
y
Supported Windows versions: Windows 7 and
Windows 8.1
y
Windows screen pivot shortcut keys
-
0°: Ctrl + Alt + Up arrow key (↑)
-
90°: Ctrl + Alt + Left arrow key (←)
-
180°: Ctrl + Alt + Down arrow key (↓)
-
270°: Ctrl + Alt + Right arrow key (→)
NOTE

LG 31MU97C Specifications

General

3D	No
DDC/CI	Yes
Color gamut	99.5 %
Pixel pitch	0.0567 x 0.1701 mm
Aspect ratio	17:9
Display diagonal	31 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	320 cd/m²
Supported graphics resolutions	4096 x 2160
Picture mode	Custom/sRGB/AdobeRGB/DCM Sim/DCI-P3 Sim./Reader/Calibration1/Calibration2
RMS rated power	10 W
Number of speakers	2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	3
Mini DisplayPorts quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	49 W
Power consumption (PowerSave)	1.2 W
Safety	UL(cUL)/CB/TCO 6.0/TUV/KC
Certification	ENERGY STAR 6.0, RoHS, Reach, Windows, FCC-B / CE
Product color	Black
Package depth	152.4 mm
Package width	972.82 mm
Package height	510.54 mm
Package weight	12020.2 g
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	AC, DisplayPort, HDMI, USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	241.3 mm
Height (with stand)	482.6 mm
Weight (with stand)	9616.158 g
Depth (without stand)	53.34 mm
Width (without stand)	736.6 mm
Height (without stand)	406.4 mm
Weight (without stand)	78925.1 g
