LG 31MU97C User Manual

ENGLISH
23
USER SETTINGS
Function
1
To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
2
Go to Function by moving the joystick.
3
Configure the options following the instructions that appear in
the bottom right corner.
4
To return to the upper menu or set other menu items, move
the joystick to ◄ or pressing ( / OK) it.
5
If you want to exit the OSD menu, move the joystick to ◄
until you exit.
Each option is described below.
Menu > Function Description
MaxxAudio MaxxAudio On
MaxxAudio
®
by Waves, recipient of a Technical GRAMMY
Award
®
is a suite of studio-quality sound tools for a superior
listening experience.
Off Disables the MaxxAudio function.
MaxxAudio
Settings
The user can set the sound quality manually.
MaxxBass Bass Enhancement.
MaxxTreble Treble Enhancement.
MaxxDialog Dialog Enhancement.
Maxx3D Enhances the three dimensional effect of the sound.
Reset Returns the sound quality to the default settings.
Midnight Mode Lets you enjoy rich and full sound at a low volume.
Function
Easy control
MaxxAudio
>
Picture Mode Custom
>
Function
Dual Color Space Off
>
SUPER ENERGY SAVING Low
>
PBP
Screen
Settings
Reset
▲/▼: Move
/ ►: OK
◄: Back

LG 31MU97C Specifications

General

3D	No
DDC/CI	Yes
Color gamut	99.5 %
Pixel pitch	0.0567 x 0.1701 mm
Aspect ratio	17:9
Display diagonal	31 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	320 cd/m²
Supported graphics resolutions	4096 x 2160
Picture mode	Custom/sRGB/AdobeRGB/DCM Sim/DCI-P3 Sim./Reader/Calibration1/Calibration2
RMS rated power	10 W
Number of speakers	2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	3
Mini DisplayPorts quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	49 W
Power consumption (PowerSave)	1.2 W
Safety	UL(cUL)/CB/TCO 6.0/TUV/KC
Certification	ENERGY STAR 6.0, RoHS, Reach, Windows, FCC-B / CE
Product color	Black
Package depth	152.4 mm
Package width	972.82 mm
Package height	510.54 mm
Package weight	12020.2 g
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	AC, DisplayPort, HDMI, USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	241.3 mm
Height (with stand)	482.6 mm
Weight (with stand)	9616.158 g
Depth (without stand)	53.34 mm
Width (without stand)	736.6 mm
Height (without stand)	406.4 mm
Weight (without stand)	78925.1 g
