LG 31MU97C User Manual

ENGLISH
25
USER SETTINGS
PBP
1
To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
2
Go to PBP by moving the joystick.
3
Configure the options following the instructions that appear in
the bottom right corner.
4
To return to the upper menu or set other menu items, move
the joystick to ◄ or pressing ( / OK) it.
5
If you want to exit the OSD menu, move the joystick to ◄
until you exit.
Each option is described below.
Menu > PBP Description
PBP Displays the screens of two input modes on one monitor.
PBP Connection
Sub Screen (Right)
HDMI 1 HDMI 2
(Mini)
DisplayPort
Thunderbolt( )
(31MU97Z model
only)
Main
Screen
(Left)
HDMI 1
- O X X
HDMI 2
O - X X
(Mini) DisplayPort
O O - X
Thunderbolt( )
(31MU97Z model only)
O O X -
Input Main Selects the video signal input of the main screen.
Sub Selects the video signal input of the sub screen.
Audio Changes the audio output in PBP mode.
Swap Toggles between the main screen and sub screen in PBP mode.
Sub Full Converts the sub screen in PBP mode to wide screen.
PBP
Easy control
PBP Off
>
Input
>
Function
Audio HDMI1
>
Swap
PBP
Sub Full
Ratio
>
Screen
Settings
Reset
PBP Preview
HDMI1
▲/▼: Move
/ ►: OK
◄: Back

LG 31MU97C Specifications

General

3D	No
DDC/CI	Yes
Color gamut	99.5 %
Pixel pitch	0.0567 x 0.1701 mm
Aspect ratio	17:9
Display diagonal	31 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	320 cd/m²
Supported graphics resolutions	4096 x 2160
Picture mode	Custom/sRGB/AdobeRGB/DCM Sim/DCI-P3 Sim./Reader/Calibration1/Calibration2
RMS rated power	10 W
Number of speakers	2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	3
Mini DisplayPorts quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	49 W
Power consumption (PowerSave)	1.2 W
Safety	UL(cUL)/CB/TCO 6.0/TUV/KC
Certification	ENERGY STAR 6.0, RoHS, Reach, Windows, FCC-B / CE
Product color	Black
Package depth	152.4 mm
Package width	972.82 mm
Package height	510.54 mm
Package weight	12020.2 g
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	AC, DisplayPort, HDMI, USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	241.3 mm
Height (with stand)	482.6 mm
Weight (with stand)	9616.158 g
Depth (without stand)	53.34 mm
Width (without stand)	736.6 mm
Height (without stand)	406.4 mm
Weight (without stand)	78925.1 g
