LG 31MU97C User Manual

ENGLISH
15
USING THE MONITOR
USING THE MONITOR
y
The following instructions are based on the
31MU97Z model. Illustrations in this manual
may differ from the actual product.
Press the joystick button, go to Menu → Easy con-
trol → Input, and then select the input option.
y
Do not press the screen for a prolonged time.
This may cause image distortion.
y
Do not display a still image on the screen
for a prolonged time. This may cause image
retention. Use a screensaver if possible.
CAUTION
y
When connecting the power cord to the out-
let, use a grounded (3-hole) power strip or a
grounded power outlet.
y
The monitor may flicker when turned on in
an area where the temperature is low. This is
normal.
y
Sometimes red, green, or blue spots may ap-
pear on the screen. This is normal.
NOTE
Connecting to a PC
y
This monitor supports the *Plug and Play fea-
ture.
* Plug and Play: A feature that allows you to add a
device to your computer without having to recon-
figure anything or install any manual drivers.
HDMI Connection
Transmits digital video and audio signals from your
PC to the monitor. Connect your PC to the monitor
using the HDMI cable as shown in the illustration
below.
DP OUT
H/P
HDMI IN 1 HDMI IN 2
HDMI IN 1 HDMI IN 2
USB IN 2USB UP USB IN 1
US
B UP
USB IN 3
DP-IN
USB IN 2USB IN 1 USB IN 3
5 V 1.1 A
5 V 1.1 A
mDP-IN
DP OUT
DP-IN
mDP OUT
y
Make sure to use the supplied HDMI cable of
the product. Otherwise, this may cause the
device to malfunction.
y
Connecting your PC to the monitor using the
HDMI cable may cause device compatibility
issues.
y
Using a DVI to HDMI / DP (DisplayPort) to
HDMI cable may cause compatibility issues.
y
Use a certified cable with the HDMI logo
attached. If you do not use a certified HDMI
cable, the screen may not display or a con-
nection error may occur.
y
Recommended HDMI cable types
-
High-Speed HDMI
®
/
TM
Cable
-
High-Speed HDMI
®
/
TM
Cable with Ethernet
CAUTION

LG 31MU97C Specifications

General

3D	No
DDC/CI	Yes
Color gamut	99.5 %
Pixel pitch	0.0567 x 0.1701 mm
Aspect ratio	17:9
Display diagonal	31 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	320 cd/m²
Supported graphics resolutions	4096 x 2160
Picture mode	Custom/sRGB/AdobeRGB/DCM Sim/DCI-P3 Sim./Reader/Calibration1/Calibration2
RMS rated power	10 W
Number of speakers	2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	3
Mini DisplayPorts quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	49 W
Power consumption (PowerSave)	1.2 W
Safety	UL(cUL)/CB/TCO 6.0/TUV/KC
Certification	ENERGY STAR 6.0, RoHS, Reach, Windows, FCC-B / CE
Product color	Black
Package depth	152.4 mm
Package width	972.82 mm
Package height	510.54 mm
Package weight	12020.2 g
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	AC, DisplayPort, HDMI, USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	241.3 mm
Height (with stand)	482.6 mm
Weight (with stand)	9616.158 g
Depth (without stand)	53.34 mm
Width (without stand)	736.6 mm
Height (without stand)	406.4 mm
Weight (without stand)	78925.1 g
