LG 31MU97C User Manual

ENGLISH
21
USER SETTINGS
User Settings
Menu Settings
1
To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the
Menu.
2
Configure the options by moving the joystick up/down/left/right.
3
To return to the upper menu or set other menu items, move the joystick to ◄ or pressing ( / OK) it.
4
If you want to exit the OSD menu, move the joystick to ◄ until you exit.
y
When you enter the menu, instructions on how to use the button will appear in the bottom right corner
of the screen.
Easy control Function PBP Screen Settings Reset
Each option is described below.
Menu Description
Easy control Brightness
Adjusts the color contrast and brightness of the screen.
Contrast
Volume Adjusts the volume level.
y
You can adjust Mute/ Unmute by moving the joystick button to ▼ in the Volume
menu.
NOTE
Input Selects the input mode.
Ratio Adjusts the aspect ratio of the screen.
Function Adjusts MaxxAudio, Picture Mode, Dual Color Space, and SUPER ENERGY SAVING.
PBP PBP Displays the screens of two input modes on one monitor.
Screen Picture Adjusts the Sharpness, Black level, and Response Time of the screen.
Color Adjusts Gamma, Color Temperature, Red, Green, Blue, and Six Color.
Settings Adjusts Language, Power LED, Automatic Standby, DisplayPort 1.2, DisplayPort EQ,
and OSD Lock.
Reset Restores the default settings.
◄ Exit Exits the OSD menu.
y
Your monitor’s OSD (On Screen Display) may differ slightly from that shown in this manual.
CAUTION

LG 31MU97C Specifications

General

3D	No
DDC/CI	Yes
Color gamut	99.5 %
Pixel pitch	0.0567 x 0.1701 mm
Aspect ratio	17:9
Display diagonal	31 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	320 cd/m²
Supported graphics resolutions	4096 x 2160
Picture mode	Custom/sRGB/AdobeRGB/DCM Sim/DCI-P3 Sim./Reader/Calibration1/Calibration2
RMS rated power	10 W
Number of speakers	2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	3
Mini DisplayPorts quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	49 W
Power consumption (PowerSave)	1.2 W
Safety	UL(cUL)/CB/TCO 6.0/TUV/KC
Certification	ENERGY STAR 6.0, RoHS, Reach, Windows, FCC-B / CE
Product color	Black
Package depth	152.4 mm
Package width	972.82 mm
Package height	510.54 mm
Package weight	12020.2 g
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	AC, DisplayPort, HDMI, USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	241.3 mm
Height (with stand)	482.6 mm
Weight (with stand)	9616.158 g
Depth (without stand)	53.34 mm
Width (without stand)	736.6 mm
Height (without stand)	406.4 mm
Weight (without stand)	78925.1 g
