LG 31MU97C User Manual

ENGLISH
24
USER SETTINGS
Menu > Function Description
Picture Mode Custom Allows the user to adjust each element. The color mode of the main menu
can be adjusted.
sRGB A standard RGB color space for the monitor and printer.
AdobeRGB A much larger color space than sRGB. This option is suitable for printing
pictures.
DCM Sim. Optimizes the screen for viewing X-ray images. You can brighten the screen
in the OSD menu.
NOTE
y
This product has been approved as an IT device and not as a
medical device. It is intended for office use only. (It may be used for
education and reference purposes but not for medical diagnosis.)
DCI-P3 Sim. Suitable for watching digital videos.
Reader Optimizes the screen for viewing documents.You can brighten the screen in
the OSD menu.
Calibration 1 Adjusts to the last calibrated screen.
Calibration 2 Adjusts to the previously calibrated screen.
Dual Color Space Off Disables the Dual Color Space function.
sRGB Sets the sRGB Picture Mode on the left of the screen.
AdobeRGB Sets the Adobe Picture Mode on the left of the screen.
DCI-P3 Sim.
Sets the DCI-P3 Sim. Picture Mode on the left of the screen.
Calibration 1 Sets the Calibration 1 Picture Mode on the left of the screen.
Calibration 2 Sets the Calibration 2 Picture Mode on the left of the screen.
SUPER ENERGY
SAVING
Conserve energy by using luminance compensation algorithm
High Saves energy using the high-efficiency SUPER ENERGY SAVING feature.
Low Saves energy using the low-efficiency SUPER ENERGY SAVING feature.
Off Disables the SUPER ENERGY SAVING feature.
NOTE
y
Saving Data depends on the Panel. These values vary by panel and vendor. If option of SUPER
ENERGY SAVING is High or Low, monitor luminance become higher or lower depend upon source.

LG 31MU97C Specifications

General

3D	No
DDC/CI	Yes
Color gamut	99.5 %
Pixel pitch	0.0567 x 0.1701 mm
Aspect ratio	17:9
Display diagonal	31 \
Display resolution	4096 x 2160 pixels
Display technology	LED
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	320 cd/m²
Supported graphics resolutions	4096 x 2160
Picture mode	Custom/sRGB/AdobeRGB/DCM Sim/DCI-P3 Sim./Reader/Calibration1/Calibration2
RMS rated power	10 W
Number of speakers	2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	3
Mini DisplayPorts quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (off)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	49 W
Power consumption (PowerSave)	1.2 W
Safety	UL(cUL)/CB/TCO 6.0/TUV/KC
Certification	ENERGY STAR 6.0, RoHS, Reach, Windows, FCC-B / CE
Product color	Black
Package depth	152.4 mm
Package width	972.82 mm
Package height	510.54 mm
Package weight	12020.2 g
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Sustainability certificates	ENERGY STAR
Cables included	AC, DisplayPort, HDMI, USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth (with stand)	241.3 mm
Height (with stand)	482.6 mm
Weight (with stand)	9616.158 g
Depth (without stand)	53.34 mm
Width (without stand)	736.6 mm
Height (without stand)	406.4 mm
Weight (without stand)	78925.1 g
