CONNECTIONS & SETUP
26
CONNECTIONS & SETUP
DIGITAL AUDIO OUTPUT
Send the TV’s audio to external audio equipment via the Digital Audio Output
(
Optical
)
port.
HDMI/DVI IN
RS-232C IN
(CONTROL & SERVICE)
ANTENNA
OUT
ANTENNA
IN
DIGITAL AUDIO DIGITAL AUDIO
OUTOUT
OPTICALPTICAL
ANTENNA
OUT
ANTENNA
IN
DIGITAL AUDIO OUT
OPTICAL
GG
When connecting with external audio equipments, such
as amplifers or speakers, please turn the TV speakers
off. (
GG
pp..6688
)
NOTE
!
GG
Do not look into the optical output port. Looking at the
laser beam may damage your vision.
CAUTION
Connect one end of an optical cable to the TV Digital
Audio
(
Optical
)
Output port.
Connect the other end of the optical cable to the digi-
tal audio
(
optical
)
input on the audio equipment.
Set the “TV Speaker option - Off” in the AUDIO
menu. (
GG
pp..6688
). See the external audio equipment
instruction manual for operation.
1. How to connect
i.e) 32/37/42LC2D*
i.e)42PC1D*, 50PC1D*, 60PC1D*
2
3
1
1
2
ANTENNA
OUT
ANTENNA
IN
DIGITAL AUDIO
OUT
OPTICAL
HDMI/DVI IN
RS-232C IN
(CONTROL & SERVICE)
ANTENNA
OUT
ANTENNA
IN
DIGITAL AUDIO OUTDIGITAL AUDIO OUT
OPTICALOPTICAL
1
2
9U0569A-1 Rev05 1/9/96 2:52 PM Page 26
