INSTALLATION
14
WIRE ARRANGEMENT
INSTALLATION
Arrange the cable as shown.
2
This function explains the features available on the 42PC1D*, 60PC1D*.
This function explains the features available on the 50PC1D*.
Hold the CABLE MANAGEMENT with both hands and pull it backward as shown.
Connect the cables as necessary.
To connect an additional equipment, see the Connections & Setup section.
1
2
Install the CABLE MANAGEMENT as shown.
3
Connect the cables as necessary.
After connecting the cables neatly, arrange the cables to the Cable Holder.
To connect an additional equipment, see the Connections & Setup section.
1
9U0569A-1 Rev05 1/9/96 2:51 PM Page 14

Table of Contents

Other manuals for LG 32LC2D

Preview: Owner's Manual
Owner's Manual68 pages
Preview: Service Manual
Service Manual40 pages
Preview: Specifications
Specifications2 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG 32LC2D and is the answer not in the manual?

LG 32LC2D Specifications

42PC1DVH

Weight and Dimensions IconWeight and Dimensions
dimensions including stand44.4 x 29.5 x 15.0 inches
dimensions excluding stand44.5 x 27.4 x 4.1 inches
weight including stand61.1 pounds / 27.7 kg
weight excluding stand53.4 pounds / 24.2 kg

42PC3D

Weight and Dimensions IconWeight and Dimensions
dimensions including stand44.4 x 29.5 x 15.0 inches
dimensions excluding stand44.4 x 27.4 x 4.1 inches
weight including stand64.4 pounds / 29.2 kg
weight excluding stand55.8 pounds / 25.3 kg

42PC3DV

Weight and Dimensions IconWeight and Dimensions
dimensions including stand44.4 x 29.5 x 15.0 inches
dimensions excluding stand44.4 x 27.4 x 4.1 inches
weight including stand62.6 pounds / 28.4 kg
weight excluding stand54.0 pounds / 24.5 kg

50PC3D

Power IconPower
power requirementAC100-240V ~50/60Hz
external antenna impedance75Ω
Operating Environment IconOperating Environment
operating temperature32 ~104°F (0 ~40°C)
operating humidityLess than 80%
storage temperature-4 ~140°F (-20 ~60°C)
storage humidityLess than 85%
Weight and Dimensions IconWeight and Dimensions
dimensions including stand51.3 x 34.3 x 14.0 inches
dimensions excluding stand51.3 x 31.9 x 4.2 inches
weight including stand114.4 pounds / 51.9 kg
weight excluding stand95.0 pounds / 43.1 kg
