11
ENGLISH
Software
Installation Priority
(required/optional)
Supported Interface Supported OS
Thunderbolt ( )
(34UM94, 34UM95
model only)
DisplayPort HDMI Mac OS (10.9 / 10.10) Linux
Screen Split Optional O O O O X
True Color Finder Optional O O X O X
TUSB3410 Driver Required O O X O X
Dual Controller Optional O O O O X
Screen Split Automatically splits the monitor screen into the desired layouts.
True Color Finder: Calibrates the color output of the monitor using the hardware calibration function.(A separate
calibrator is required.)
TUSB3410 Driver: This driver file is required for USB communication between the monitor and the PC software.
Dual Controller Software that makes it possible to use a PC's keyboard and mouse to control other PCs connected to the
same network (router).
The software listed above can be installed using the CD provided with the product or downloaded as the latest version
from the LG Electronics website.
Graphics card Use a graphics card that supports 3440 x 1440 resolution.
Available Product and OS
Dual Link-Up (Monitor PBP Function)
Usage The monitor displays screens for 2 input sources simultaneously.
The Dual Link-Up feature requires that one of the two input sources is connected via HDMI.
Image shown may differ from the product that you are using.
How to Run
1. Connect the monitor to two input sources.
2. Press the joystick button on the bottom of the monitor.
3. Enter
1
PBP.
4. Adjust the settings according to the input sources
connected.
5. DUAL LINK-UP is applied.
For details on using the software, refer to the product user manual.
The product user manual is included on the CD provided and is available for download from the LG Electronics website.
PBP Connection
Sub screen (Right)
HDMI 1 HDMI 2 DisplayPort
Thunderbolt ( )
(34UM94, 34UM95 model only)
Main screen
(Left)
HDMI 1 - O X X
HDMI 2 O - X X
DisplayPort O O - X
Thunderbolt ( )
(34UM94, 34UM95 model only)
O O X -
Main screen Sub screen
Reader
Menu PBP
Monitor off
Exit
1
To Next Page
