MAKING CONNECTIONS

Thenumberofmonitorsthatcanbeconnectedtooneoutputmayvarydependingonsignalstatus
andcableloss.Ifthesignalstatusisgood,andthereisnocableloss,itispossibletoconnectupto
9monitors.Ifyouwanttoconnectmorethanthisnumberofmonitors,itisrecommendedtousea
distributor.

Whenmulti-connectingin/outcascadeformat,nolosscablesarerecommended.

DVIOUTdoesnotworkwhenconnectingtoathird-partyproduct.
NOTE
Daisy Chain Monitors
UsethisfunctiontosharetheRGBvideosignalwithothermonitorswithouthavingtouseaseparatesignal
splitterbox.
•TousedifferentproductsconnectedtoeachotherConnectoneendofthesignalinputcable(15-pin
D-SubSignalCable)totheRGBOUTconnectorofproduct1andconnecttheotherendtotheRGBIN
connectorofotherproducts
AV IN / OUT
VIDEO
IN
OUT
AUDIO
AV IN / OUT
VIDEO
IN
OUT
AUDIO
AV IN / OUT
VIDEO
IN
OUT
AUDIO
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
Monitor1 Monitor2 Monitor3 Monitor4
RGB Cable
15-pinD-SubSignalCable
(Max3m)
DVI Cable
DVI IN DVI OUT DVI IN DVI OUT DVI IN DVI OUT DVI IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
RGB/AV
/COMPONENT OUT
RGB/AV
/COMPONENT IN
DVICable
Monitor1 Monitor2 Monitor3 Monitor4
