LG 55SE3B User Manual

10
ASSEMBLY AND PREPARATION
ENGLISH
IR&LIGHT
SENSOR
LAN
SPEAKER
OUT
RS-232C
IN
RS-232C
OUT
EXT IR
IN
AUDIO
OUT
AUDIO
IN
DVI-D IN LAN
USB 1
5 V 1.0 A
USB 2
5 V 1.0 A
RGB IN
Parts and Buttons
Connection
Panel
Buttons
Buttons Description
INPUT Changes the input source.
MENU Accesses the main menus, or saves your input and exits the menus.
Adjust the up and down.
Moves left and right.
AUTO/SET Displays the current signal and mode.
/ I
Turns the power on or off.
- The image may be different according to the model
(Only for
**SE3B/**SL5B
model)
32/43/49/55SE3B 32/43/49/55SE3KB
43/49/55SL5B

LG 55SE3B Specifications

General

Panel life	30000 h
Color gamut	68 %
Response time	12 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Supported video modes	1080i, 1080p, 720p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1100:1
Display number of colors	1.073 billion colors
Audio input	1
Sound modes	Game, Music, Standard, Movie, News, Sports
Temperature indicator	Yes
USB ports quantity	2
Multi-display supported	-
On Screen Display (OSD) languages	DUT, NOR, ENG, ESP, ITA, SWE, CHI (SIMPL), POR, CHI (TR), FIN, FRE, KOR, RUS, CZE, GRE, DAN, DEU
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	300 x 300 mm
Certification	UL / cUL / CB / TUV / KC / FCC Class \
RMS rated power	20 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (typical)	70 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, VGA
Package depth	149.86 mm
Package width	1330.96 mm
Package height	812.8 mm
Package weight	21500 g

Weight and Dimensions

Depth	38.6 mm
Width	1238 mm
Height	714.9 mm
Weight	17300 g
