- 129 -
Outdoor Unit Parts List (A2UN186FA0/A3UN216FA0)
PART No.
A2UN186FA0 A3UN216FA0
137213-1 PANEL ASSEMBLY, SIDE 1A00201D 1A00201D R
137213-2 PANEL ASSEMBLY, SIDE 3A02284W 3A02284W R
263230-4 THERMISTOR ASSEMBLY 6323A20002Q 6323A20002Q R
263230-3 THERMISTOR ASSEMBLY 6323A20002R 6323A20002R R
263230-2 THERMISTOR ASSEMBLY - 6323AQ3226K R
269310-1 THERMISTOR ASSEMBLY 6323A20001A 6323A20001A R
349480 ORIFICE 4948AP2527A 4948AP2527A R
349600 MOUNT, MOTOR 4960AP1361A 4960AP1361A R
430410 BASE ASSEMBLY, WELD(OUTDOOR) 3041A20022B 3041A20022B R
435300 GRILLE, REAR 1A00207B 1A00207B R
435301 GRILLE, DISCHARGE 3530A20007B 3530A20007B R
435511
COVER ASSEMBLY, CONTROL(OUTDOOR)
3551A10003Y 3551A10003Y R
435512 COVER ASSEMBLY, TOP(OUTDOOR) 3H03266L 3H03266L R
437210 PANEL ASSY, FRONT SUB 3721A20004L 3721A20004L R
447910 BARRIER ASSEMBLY, OUTDOOR 2H02110L 2H02110L R
546810 MOTOR ASSEMBLY, OUTDOOR 4681A20013Z 4681A20013Z R
552113 TUBE ASSEMBLY, CONDENSER OUT 5211A20954A 5211A20954A R
552115 TUBE ASSEMBLY, MENIFOLD(OUTDOOR) 5211A20419C 5211A20419A R
552116 TUBE ASSEMBLY, REVERSING 5211A20590A 5211A20949A R
552203-1 VALVE, SERVICE 5220A20035A 5220A20035A R
552203-2 VALVE, SERVICE 5220A20034A 5220A20034A R
554031 CONDENSER ASSEMBLY, BENT 5403A20072L 5403A20072L R
554160 COMPRESSOR 2520UTGV2AA 2520UTGV2AA R
559010 FAN ASSEMBLY, PROPELLER 1A00195B 1A00195B R
561410 COIL ASSY, REVERSING VALVE 6141AR3509A 6141AR3509A R
649950 CONTROL BOX ASSEMBLY, OUTDOOR 4995A10053J 4995A10053G R
561411-1 COIL ASSEMBLY, EXPANSION 6141A30003B 6141A30003B R
561411-2 COIL ASSEMBLY, EXPANSION 6140A30003C 6140A30003C R
561411-3 COIL ASSEMBLY, EXPANSION - 6141A30003D R
566000 SWITCH, PRESSURE 3A02524F 3A02524F R
658740 REACTOR 5874A90001E 5874A90001E R
668711 PWB(PCB) ASSEMBLY, MAIN(OUTDOOR) 6871A20204Q 6871A20204R R
W6200 FILTER(CIRC), EMC 6200JB8007Q 6200JB8007Q R
668713 PWB(PCB) ASSEMBLY, SUB 6871A20205A 6871A20205A R
669200 RELAY 6920AP3400A 6920AP3400A R
W0CZZ-1 CAPACITOR, DRAWING 0CZZA90001C 0CZZA90001C R
W0CZZ-2 CAPACITOR, DRAWING 0CZZA90001D 0CZZA90001D R
W0CZZ-3 CAPACITOR, DRAWING 2A00986D 2A00986D R
738281 MANUAL, SERVICE 3828A20097N 3828A20097N R
738290 MANUAL, OWNERS 3828A20331A 3828A20331A R
W6640-1 TERMINAL BLOCK 3A00093A 3A00093A R
W6640-2 TERMINAL BLOCK 4G00103C 4G00103C R
DESCRIPTION
REMARKS
LOCATION
No.
