3-11
3. TRAY OPEN/CLOSE SIGNAL
1) Tray open/close waveform
OPEN((PDM03 PIN7)
CLOSE(PDM03 PIN8)
TROPEN(IC402 PIN 4)
TRCLOSE(IC402 PIN 5)
FIG 3-1
2) Tray close waveform
OPEN((PDM03 PIN7)
CLOSE(PDM03 PIN8)
TROPEN(IC402 PIN 4)
TRCLOSE(IC402 PIN 5)
FIG 3-2
