LG ACHH017VBAB - Specifications

11
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
SPECIFICATIONS
Table 1: Specication Data for 208-230V Heat Pump Chiller.
ACHH017VBAB ACHH020VBAB ACHH033VBAB ACHH040VBAB
H/P H/P H/P H/P
Phase, Lines, V, Hz
RT
16.2 18.5 32.42 37
kBtuh/h
194.5 222 389 444
Heang
kBtuh/h
204.5 239 409 478
Cooling
kW
18.1 21.5 36.2 43.0
Heang
kW
19.1 22.6
38.1 45.2
Cooling
EER btuh/W
10.75 10.33 10.75 10.33
Heang
COP
3.15 3.1 3.15 3.1
btuh/W 19.46
19.46
19.46 19.46
Sound Power Cooling
dB(A)
78 78 86 87
Sound Pressure 30' Cooling
dB(A)
49 51 52 54
Sound Pressure 5' Cooling
dB(A)
69 71 72 74
Sound Power Heang
dB(A)
83 83 86 87
Sound Pressure 30' Heang
dB(A)
49 51 52 54
Sound Pressure 5' Heang
dB(A)
69 71 72 74
No. of Compressors
EA 2 2 4 4
Oil Charge Each Compressor
OZ/EA 33.8 33.8 33.8 33.8
Amount of Charge EA Circuit
lbs/EA 15.4 15.4 15.4 15.4
Quanty EA 1 1 2 2
Pressure Drop Aq
2.7 3.1 2.7 3.1
Operang Maximum Pressure
(Refrigerant/Water)
psi 597/142 597/142 597/142 597/142
Cooling Water Flow (10F Delta) GPM 38.9 44.4 77.8 88.7
Inlet/Outlet Water Connecon inches/ange 2"/150 lb 2"/150lb 2 1/2"/150lb 2 1/2"/150lb
No. of Fan Motors
EA
2 2 4 4
No. of Blades per Fan
EA
6 6 6 6
Air Flow Rate
CFM
8684 8684 8684 8684
Motor Power
W
900 900 900 900
Metering
lbs 1162 1162 2218 2218
W
inches
30 1/8 30 1/8 60 5/8 60 5/8
H
inches
86 5/8 86 5/8 86 5/8 86 5/8
D
inches
84 13/16 84 13/16 84 13/16 84 13/16
2/RT
1.09 0.96 1.09 0.96
High/Low Pressure
Electronic
Flow Switch
Paddle/ADJ.
Freeze Protecon
On/O Contact Only
Type
Cooling
F
Heang
F
Approved Water Delta T
Cooling and Heang
F
Cooling
F
Heang
F
%
3,3,208-230,60
EEV
Remote Monitoring and Control
Modbus (Oponal BACnet Gateway)
Heat Trace Elements and Power by Others
Power
Variable BLDC
Stainless Plate
410A
Inverter Scroll
PVE
Internal
Internal
Fan Motor
Dimensions
Protecon Devices
14-68
86-131
5-125
-22-95
20-100
04-20
Supply Water Temperature
Range
Ambient Temperature
Operaonal Range
Guaranteed Load Capacity Range
Type
Type
Weight
Foot Print
Refrigerant
Model
Type
Type
Type
Evaporator
Cooling
IPLV
Oil Type
Inverter Scroll Chiller
Capacity
Input Power
Eciency
Compressor
