LG Air-Cooled Heat Pump Inverter Scroll Chiller Installation and Owners Manual
2. Hot Water Set Point (2 ~ 10 V, 4 ~ 20 mA)
: UI3 (M ode Heat)
Volt [V]
500Ω
[mA]
Heat Set Point
(30 ~ 70) [°C]
Heat Set Point
(86 ~ 158) [°F]
Etc
0.0 0.0
No Control
(Disconnected)
No Control
(Disconnected)
0.2 0.4
0.4 0.8
0.6 1.2
0.8 1.6
1.0 2.0
1.2 2.4
1.4 2.8
1.6 3.2
1.8 3.6
2.0 4.0 30 86
2.2 4.4 31 87.8
2.4 4.8 32 89.6
2.6 5.2 33 91.4
2.8 5.6 34 93.2
3.0 6.0 35 95
3.2 6.4 36 96.8
3.4 6.8 37 98.6
3.6 7.2 38 100.4
3.8 7.6 39 102.2
4.0 8.0 40 104
4.2 8.4 41 105.8
4.4 8.8 42 107.6
4.6 9.2 43 109.4
4.8 9.6 44 111.2
5.0 10.0 45 113
5.2 10.4 46 114.8
5.4 10.8 47 116.6
5.6 11.2 48 118.4
5.8 11.6 49 120.2
6.0 12.0 50 122
6.2 12.4 51 123.8
6.4 12.8 52 125.6
6.6 13.2 53 127.4
6.8 13.6 54 129.2
7.0 14.0 55 131
REMOTE DESIRED TEMPERATURE CONTACT
POINTS
