LG Air-Cooled Heat Pump Inverter Scroll Chiller Installation and Owners’ Manual
STORING THE CHILLER / INSTALLING ANCHOR
BOLTS
Anchor Bolt Locking Points
Anchor Bolt Locking Points
Figure 27: Anchor Bolt Locking Points on the Chiller.
Installing Anchor Bolts (Field-Supplied)
• The wooden shipping pallet at the bottom of the chiller must be
removed before installation and tightening the anchor bolts.
• Use anchor bolts to firmly attach the chiller to the installation area
/ base.
• Tighten the bolts so that the chiller does not fall over from strong
winds or earthquakes. Must be engineered by local professional.
• Noise and operation vibration from the chiller can be transferred to
the floor or wall of the installation area. Add anti-vibration material
to reduce its impact.
• Follow all local, state, and federal codes for securing chiller and
base design.
• Open the left / right panels of the chiller, find the anchor bolt lock-
ing points, check anchor bolt attachment hole, and lock the anchor
bolts so the bolts are at right angles to the chiller.
