Solar Heating System Piping
Solar Heating System Interface Kit (PHLLA)
Hydro Kit Medium Temperature (K2 Only)
Refer to Figure 23 as a guide when installing the Solar Heating System Interface Kit onto the Hydro Kit Medium Temperature Chassis.
Refer to the Solar Heating System Interface Kit Installation Manual for specific installation procedures.
Dual Source Hydronic Heating Schematic
Figure 23: Dual Source Hydronic Heating Schematic
Solar
Thermal
System
(Field Supply)
Solar
Collector
(Field Supply)
Indirect Water
Storage Tank
Water Tank Sensor
Cable
Solar Thermal Sensor Cable
(39 Ft)
(39 Ft)
Water In
Water Out
Water Out
Water In
3way valve
(Field Supply)
Pump
(Field Supply)
Sensor & Sensor
Pipe Tee Well
ROUGHING-IN
