LG ARNH963K2A2 - Water Piping Schematic

33
Installation
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp.
Figure 24: DomesticWaterStorage,In-oor,Inductive(Radiator)andForcedAirHydronicHeatingDiagram
Floor Heating (With Mixing Tank)
Water Piping Schematic
M
Floor heating circuitFan coil unit
Symbols Key:
= Pump
B = Balancing Valve
M = Modulating two-way Valve
M = Modulating three-way Valve
Indirect
Water
Storage
Tank
Hot water
City water
Radiator
K2 or K3
ROUGHING-IN
