MULTI V Wall-Mounted Indoor Unit Engineering Manual
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
STANDARD WALL-MOUNTED
&RROLQJ&DSDFLW\7DEOHV
ARNU123SBL4, ARNU153SBL4, ARNU183SCL4
Table 32: ARNU123SBL4, ARNU153SBL4, ARNU183SCL4 Cooling Capacity Table.
Model No. /
Capacity Index
Outdoor
Air Temp.
(°F DB)
Indoor Air Temperature (°F DB / WB)
68 / 57 73 / 61 79 / 64 80 / 67 85 / 70 88 / 73 91 / 76
TCSHCTCSHCTCSHCTCSHCTCSHCTCSHCTCSHC
MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh MBh
ARNU123SBL4 /
12.3
23 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
25 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
30 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
35 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
40 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
45 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
50 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
55 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.9 8.7
60 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.7 8.7
65 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.5 8.5
70 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 15.3 8.4
75 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.7 8.7 14.9 8.2
80 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.8 8.8 14.2 8.7 14.5 8.2
85 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.6 8.7 13.8 8.3 14.0 7.8
90 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.4 8.6 13.5 8.2 13.8 7.7
95 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 13.2 8.5 13.4 8.1 13.6 7.7
100 8.1 6.3 9.8 7.2 11.1 7.7 12.3 8.2 12.9 8.4 13.2 8.0 13.4 7.6
105 8.1 6.3 9.3 6.9 10.6 7.4 11.8 7.8 12.0 7.8 12.7 7.7 12.9 7.4
110 7.9 6.1 8.9 6.5 9.8 6.9 11.1 7.4 11.3 7.4 12.0 7.4 12.6 7.2
ARNU153SBL4 /
15.4
23 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
25 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
30 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
35 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
40 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3
11.4 18.4 11.3 19.9 11.3
45 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
50 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
55 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.9 11.3
60 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.7 11.2
65 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.4 11.0
70 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 19.1 10.8
75 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 18.4 11.3 18.6 10.6
80 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.3 11.4 17.8 11.2 18.2 10.6
85 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 17.1 11.3 17.3 10.7 17.6 10.1
90 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 16.8 11.1 16.9 10.6 17.3 10.0
95 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 16.5 11.0 16.8 10.5 17.1 9.9
100 10.1 8.1 12.3 9.4 13.9 10.0 15.4 10.6 16.2 10.8 16.5 10.4 16.8 9.8
105 10.1 8.1 11.7 8.9 13.2 9.5 14.8 10.1 15.1 10.1 15.8 10.0 16.2 9.6
110 9.9 7.9 11.1 8.4 12.3 8.9 13.9 9.5 14.2 9.5 15.1 9.5 15.7 9.3
ARNU183SCL4 /
19.1
23 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
25 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
30 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
35 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
40 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
45 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
50 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
55 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.7 13.8
60 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.4 13.7
65 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 24.0 13.5
70 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 23.7 13.3
75 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.8 13.8 23.1 13.0
80 12.6 9.9
15.3 11.4 17.2 12.2 19.1 13.0 21.4 13.9 22.1 13.7 22.5 12.9
85 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 21.2 13.8 21.4 13.1 21.8 12.4
90 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 20.9 13.6 21.0 12.9 21.4 12.2
95 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 20.5 13.5 20.9 12.8 21.2 12.1
100 12.6 9.9 15.3 11.4 17.2 12.2 19.1 13.0 20.1 13.3 20.5 12.7 20.9 12.0
105 12.6 9.9 14.5 10.9 16.4 11.7 18.3 12.4 18.7 12.4 19.7 12.2 20.1 11.7
110 12.3 9.6 13.8 10.3 15.3 10.9 17.2 11.7 17.6 11.7 18.7 11.7 19.5 11.4
TC: Total Capacity (MBh); SHC: Sensible Heat Capacity (MBh).
