LG ARNU093SBL4 User Manual

ART COOL
TM
| 9
Art Cool
TM
Gallery
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©
/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
ART COOL
TM
GALLERY
General Data / Electrical Data
Table 1: Art Cool Gallery (SF Frames) Indoor Unit General Data.
EEV: Electronic Expansion Valve
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry nitrogen charge.
This data is rated 0 ft above sea level, with 25 ft of refrigerant line per indoor unit and a 0 ft level
difference between outdoor and indoor units. All capacities are net with a combination ratio between
95-105%.
Cooling capacity rating obtained with air entering the indoor coil at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and outdoor
ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
1
Power Input is rated at high speed.
2
Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3
Sound Pressure levels are tested in an anechoic chamber under ISO Standard 3745.
4
All communication cable to be minimum 18 AWG, 2-conductor, stranded, shielded and must comply
with applicable and national code. Ensure the communications cable is properly grounded at the master
outdoor unit only. Do not ground the ODU-IDU communications cable at any other point.
Model No. ARNU093SFA4 ARNU123SFA4
&RROLQJ0RGH3HUIRUPDQFH
Capacity (Btu/h)
9,600 12,300
Power Input
1
(W)
35 35
+HDWLQJ0RGH3HUIRUPDQFH
Capacity (Btu/h)
10,900 13,600
Power Input
1
(W)
35 35
(QWHULQJ0L[HG$LU
Cooling Max (°F WB)
76 76
Heating Min (°F DB)
59 59
8QLW'DWD
Refrigerant Type
2
R410A R410A
Refrigerant Control
EEV EEV
Sound Pressure
3
dB(A) (H/M/L)
38 / 32 / 27 44 / 38 / 32
Net Unit Weight (lbs.)
33.1 33.1
Shipping Weight (lbs.)
38.1 38.1
Communication Cable
4
(No. x AWG)
2 x 18 2 x 18
)DQ
Type
Turbo Fan Turbo Fan
Quantity
11
Motor/Drive
Brushless Digitally Controlled / Direct
Airflow Rate H/M/L (CFM)
286 / 222 / 148 328 / 272 / 212
3LSLQJ
Liquid Line (in., O.D.)
1/4 Flare 1/4 Flare
Vapor Line (in., O.D.)
1/2 Flare 1/2 Flare
Condensate Line (in., I.D.)
5/8 5/8
MCA: Minimum Circuit Ampacity.
MOP: Maximum Overcurrent Protection.
Units are suitable for use on an electrical system where voltage supplied to unit terminals is within the listed range limits.
Select wire size based on the larger MCA value.
Instead of a fuse, use the circuit breaker.
Model Number
Voltage
Range
MCA MOP Rated Amps (A)
Power Supply Power Input (W)
Hz Volts Phase Cooling Heating
6))UDPHV
ARNU093SFA4
187-253 0.4 15 0.3 60 208-230 1 35 35
ARNU123SFA4
Table 2: Art Cool Mirror Wall-Mounted Indoor Unit Electrical Data.
