Appendix74
Appendix
6
Specifications
General
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions (W x H x D) Approx. 950 mm x 136 mm x 75 mm
Net Weight (Approx.) 4.5 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs/Outputs
HDMI IN/OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1
PORT. IN 0.5 Vrms (3.5 mm stereo jack) x 1
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
Amplier
Power output, (RMS), THD 10 %
Total 330 W
Front 60 W x 2
Rear 30 W x 2
Sub-Woofer 150 W
