4. TROUBLE SHOOTING
- 109 -
Fig. 4.9.3 Check Flow of the Bluetooth Block
Start
TP1,TP2
Sig nals ex its?
TP3
Is c lock ok ? 19.2M
TP4
Sig nals ex its?
Chang e th e Main bo ard
YES
YES
YES
Chan ge the U101
NO
NO
Chan ge the X100
NO
Chan ge the ma in board
